Wheel Loader
WL816
Certified
ISO9001:2008
Certified
Certified
Certified
Wheel Loader
Certified
ISO9001:2008
Certified
Certified
Certified
Standard Configurations
Xinchai A498BT1 Euro 3 engine, electronic control joystick, 4 hydraulic lines, LED lights, back camera,Varta Battery, 20.5-16 tires, floating function, luxury cabin with heater, 220V engine preheat, warning light,adjustable steering wheel and seat, bucket can be level automatic, back sound, radio, fan, hand brake,extinguisher, window hammer, Free parts, tool box.
Optional
Xinchai Euro V engine, Yanmar/Kohler EPA 4/ Euro V, quick hitch, air conditioning, electric floating, diesel heater, all kinds of attachements etc.
| Type | Data |
|---|---|
| Bucket Capacity (Cbm): | 0.8-0.9 |
| Rated Load (Kg): | 1600 |
| Max. Load (Kg): | 1700 |
| Overall Weight (Kg): | 3900 |
| Dumping Clearance (mm): | 2180 |
| Standard Engine: | XINCHAI A498BT1 |
| Rated Power (Kw): | 36.8 |
| Rated Speed (R/Min): | 2400 |
| Optional Engine: | XICHAI/YUNNEI/CHANGCHAI/KOHLER |
| Wheel Base (mm): | 1500 |
| Tread (mm): | 2280 |
| LX WXH (mm): | 4950×1750×2565 |
| Standard Tire: | 20.5/70-16 |
| Option Tire: | 33X16.5-15 |
| Max. Driving Speed (km/h): | 18-28 |
