Products

Wheel Loader

Responsive image

WL812

SPECIFICATIONS
Dimensions(mm)

4600×1760×2400

Engine Model

XINCHAI C490BPG

Power(KW)

36.8

Introduce

1. Safe condition: loader cab we choose ROPS FOPS standard, cab inside we move the starter key to the joystick box to avoid of leg touch key, seat with a safe belt keeps you seat better in the hard work condition. Silicone oil shock absorption makes it more comfortable for the driver.

2. Operate condition: flexible turn angle design even on narrow and hard roads you can turn the loader easily, in the cab big room and complete windscreen glass provide the operator with an excellent view. An adjustment dashboard will help the operator drive better. under the counterweight, we design individual battery charge plugs so operators can charge power easily.

3. Fix condition: tips side cab design makes the operator change the transmission oil and filter very easily.

Standard configuration

Changchai 490 engine, electronic control joystick, 4 hydraulic lines, LED lights, back camera, Varta Battery, 20.5-16 tires, floating function, luxury cabin with heater, 220V engine preheat, warning light, adjustable steering wheel, and seat, the bucket can be level automatic, back sound, radio, fan, hand brake, extinguisher, window hammer, Free parts, toolbox.

Optional

Xinchai Euro 3/Euro 5 engine/Yanmar engine, Quick Hitch, double heater, air conditioning, different attachments, etc.

Specifications

TypeData
Bucket Capacity (Cbm):0.6-0.9
Rated Load (Kg):1200
Max. Load (Kg):1400
Overall Weight (Kg):3500
Dumping Clearance (mm):1950
Standard Engine:XINCHAI C490BPG
Rated Power (Kw):36.8
Rated Speed (R/Min):2650
Optional Engine:XICHAI/YUNNEI/CHANGCHAI/KOHLER
Wheel Base (mm):1360
Tread (mm):2200
LX WXH (mm):4600×1760×2400
Standard Tire:31X15.5-15
Option Tire:31X16.5-15
Max. Driving Speed (km/h):18-28
