WL922

SPECIFICATIONS
Dimensions(mm)

5900×2055×2615

Engine Model

CHANGCHAI 490

Power(KW)

39

Specifications

TypeData
Bucket Capacity (Cbm):0.9-1.1
Rated Load (Kg):2000/600
Overall Weight (Kg):3300
Dumping Clearance (mm):2850/3200
Standard Engine:CHANGCHAI 490
Rated Power (Kw):39
Rated Speed (R/Min):2400
Optional Engine:XI CHAI/XIN CHAI
Wheel Base (mm):1500
Tread (mm):2100
LX WXH (mm):5800×1700×2820
Standard Tire:20.5-16
Option Tire:31×15.5-15
Max. Driving Speed (km/h):18-20
