WL922 is one of the most popular wheel loader in South America and Africa, especially in farm and construction. Economical and practical, it could replace 4-5 manpower.
Standard configuration:
Changchai 490 engine,4WD, 20.5/70-16 tires, mechanical joystick, standard bucket, Camel Battery, luxury cabin, the bucket can be level automatic, back sound, hand brake, extinguisher, window hammer, Free parts, toolbox.
Optional:
Xinchai Euro 3 engine/Yanmar engine, Quick Hitch, double heater, air conditioning, electric floating, extra Hydraulic Line, electronic joystick, different attachments, etc.
Type | Data |
---|---|
Bucket Capacity (Cbm): | 0.9-1.1 |
Rated Load (Kg): | 2000/600 |
Overall Weight (Kg): | 3300 |
Dumping Clearance (mm): | 2850/3200 |
Standard Engine: | CHANGCHAI 490 |
Rated Power (Kw): | 39 |
Rated Speed (R/Min): | 2400 |
Optional Engine: | XI CHAI/XIN CHAI |
Wheel Base (mm): | 1500 |
Tread (mm): | 2100 |
LX WXH (mm): | 5800×1700×2820 |
Standard Tire: | 20.5-16 |
Option Tire: | 31×15.5-15 |
Max. Driving Speed (km/h): | 18-20 |
