Telehandler
3350T
Telehandler
The 3350T telescopic telehandler combines power andreliable performance for demanding tasks. With a3.5-ton lifting capacity and a 7-meter reach, it handleshigh-altitude operations with ease. Equipped with apowerful 76kW Yunnei engine, it also offers Euro5 andEPA Tier 4 options for different emission standardFour-wheel steering enhances flexibility, while the hy-draulic quick hitch allows for efficient attachmentchanging. With fully electronic controls and optionalproportional control, it offers user-friendly operation.The 3350T is a dependable solution for enhancing efficiency and meeting various worksite.
| Applicable Industries | Farms,Home Use,Construction works |
| Condition | New |
| Dimensions | 5870×2200×2550mm |
| Warranty | 1 Year |
| Engine Brand | YUNNEI |
| Power | 76kw |
| Bucket capacity | 1.2-2.5m³ |
| Rated loading | 3500kg |
| Overall weight | 7500kg |
| Max.lift height | 7000mm |
| Max.dump height | 5450mm |
| Min.turning radius | 5600mm |
| Max.tractive force | 480KN |
| Max.grade ability | 25° |
| Max.steering angle | 30° |
| Oscillation angle | 8° |
| Type | Water cooled,four stroke |
| Displacement | 4.33L |
| Torque converter | HK280 |
| Gearbox mode | Speed changes are electronically controlled |
| Gear shift | Two forward shift, Two reverse shift |
| Max.speed | 30km/h |
| Wheel base | 2940mm |
| Wheel tread | 1860mm |
| Ground clearance | 260mm |
| System working pressure | 18MPa-25MPa |
| Boom lifting time | 5.6s |
| Total time | 9.9s |
| Service brake | Air assist disc brake on 4 wheels |
| Parking brake | Manual disc brake |
| Type specification | 16/70-20 |
