Specifications

		ZJ25	ZJ35	ZJ45	ZJ60	ZJ65	ZJ75	ZJ100
Operating load	kg	300	500	700	850	950	1050	1200
Max Speed	km/h	9	12	12	12	12	12	12
Rated flux	L/min	50	60	62.5	75	75	75	88
High Flow Flux	L/min	/	/	/	/	125	125	125
Tire(track)	model	5.7-12	8.5-15	10-16.5	12-16.5	12-16.5	12-16.5	12-16.5
Rated power	Kw	18.4	29.4	37	45	55	55	75
Fuel tank capacity	L	25	60	70	80	80	75	90
Self weight bucket	kg	1500	2300	2700	2800	3350	3500	3600
Bucket capacity	m3	0.2	0.3	0.4	0.4	0.5	0.5	0.55
A. Overall operating height	mm	3401	3300	3980	4000	4000	4070	4070
B. Height to bucket hinge pin	mm	2477	2725	3080	3100	3100	3280	3150
C. Height to top of cab	mm	1812	2000	2140	2160	2180	2180	2180
D. Height to bottom of level bucket	mm	2446	2558	2913	2933	2962	3140	3140
E. Without bucket length	mm	2267	2300	2640	2750	2880	2880	2963
F. Overall length with bucket	mm	2768	2950	3420	3490	3392	3580	3735
G. Dumping angle at maximum height	°	40	40	40	40	40	40	40
H. Dumping height	mm	1990	2050	2380	2400	2400	2500	2500
I. Dumping reach	mm	419	790	700	750	750	700	673
J. Rollback of bucket on ground	°	30	30	30	30	30	30	30
K. Rollback of bucket at full height	°	103	104	104	104	104	104	104
L. Wheelbase	mm	801	897	991	991	991	1080	1115
M. Ground clearance	mm	145	140	185	205	210	205	205
N. Angle of departure	°	20	20	20	20	20	20	20
O. Front turning radius without bucket	mm	960	1098	1168	1193	1300	1250	1300
P. Front turning radius	mm	1660	1760	1958	1953	2290	2112	2290
Q. Rear turning radius	mm	1253	1296	1630	1723	1440	1774	1540
R. Rear axle to bumper	mm	910	964	1108	1208	1080	1082	1284
S. Thread width	mm	785	1080	1450	1500	1500	1500	1500
T. Width	mm	880	1350	1720	1880	1680	1880	1880
U. Bucket width	mm	915	1400	1740	1880	1730	1880	1880
