Forklift
WF300
Forklift
| Specification | WF300 | ||
|---|---|---|---|
| Characteristics | |||
| Fuel type | - | Diesel | |
| Load capacity | kg | 3000 | |
| Load center | mm | 500 | |
| Lift height | mm | 3000 | |
| Full free lift height | mm | 100 | |
| Fork dimension | mm | 1070×125×45 | |
| Mast tilting angle | Front/Rear | Deg. | 6/12 |
| Min. turning radius | mm | 2400 | |
| Groud clearance | mm | 135 | |
| Overhead guard height | mm | 2165 | |
| Front overhang | mm | 490 | |
| Performance | |||
| Max. travel speed | Full load | km/h | 20 |
| Max. lift speed | Full load | mm/s | 480 |
| Max. traction power | Full load | KN | 20 |
| Dimensions | |||
| Max. gradeability | % | 20 | |
| Total length | With fork | mm | 3770 |
| Total length | Without fork | mm | 2700 |
| Total width | mm | 1225 | |
| Mast extended height | mm | 4265 | |
| Mast lowered height | mm | 2060 | |
| Chassis | |||
| Tyres | Front | - | 28*9-15-12PR |
| Rear | - | 6.50-10-10PR | |
| Wheelbase | mm | 1700 | |
| Tread | Front/Rear | mm | 1000/970 |
| Service weight | Kg | 4350 | |
| Drive | |||
| Battery | Model | V/Ah | 12/80 |
| Motor | Power | - | Xinchai 490 |
